CHAPTER 27
PAGE 19
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
27-20-02 Bottom Hinge Bellcranks
Removal/Installation
1 Remove the rudder per Chapter 27-20-00.
2 Loosen the attachment bolts.
3 Remove the bottom hinge bellcranks.
4 Install in reverse sequence of removal.
27-20-03 Control Cable
Removal
1 Remove the respective access panels.
2 Remove the front cable attachment bolts.
3 Remove the cable to rudder bellcrank attachment bolts.
4 Cut the control cable behind the front shrinking sleeve.
5 Remove the control cable by pulling it out to the back.
Installation
Refer to Figure 17.
Use only control cables manufactured by EXTRA
Flugzeugproduktions- und Vertriebs GmbH. Those cables
are prepared for simply installation.
1 Remove the respective access panels per Chapter 51.
2 Move the pedal adjustment in a position as shown in Figure
15.
