CHAPTER 27
PAGE 22
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014
8 Slip 80 mm Ø 1/4" heat shrinking sleeve (2) and 850 mm
protective PTFE hose on the control cable end. The protec-
tive PTFE Hose shall extend 120 mm beyond the first
fairlead inside the fuselage.
9 Pre-install the LN 9037-06030 bolt (5), the DIN 125-8,4
washers (7)(one on both sides of the thimble and one below
the tailwheel steering attachment bracket), the DIN 125-
6,3 washers (6), the bushing (11), the LN 9348-06 nut (8)
and the thimble (10) to the bottom hinge bellcrank.
10 Slip a further 80 mm Ø 3/8" shrinking sleeve and the
NICOPRESS (National Telephone Supply Co., Cleveland
Ohio) 28-3-M sleeve on the cable end.
11 Move the cable around the thimble and tighten to a cable
tension that is just sufficient to release the template at the
rudder pedal.
I M P O R T A N T Clamping has to be performed in accordance with the
Service Bulletin 300-1-93 and the Instruction No. 32 of
the National Telephone Supply Co., Cleveland Ohio.
12 Consider to let a distance of 1 mm between the thimble and
the sleeve and clamp the sleeve.
13 Cut the free end of the cable 20 mm in front of the sleeve.
14 Move the PTFE protective hose back to the sleeve.
15 Move/slip the 80 mm Ø 3/8" shrinking sleeve to the
NICOPRESS sleeve and heat up with a heat gun.
16 Move and center the other 80 mm Ø 1/4" shrinking sleeve
to the front end of the PTFE protective hose and heat up
with a heat gun.
17 Follow the steps 5 to 16 for the LH control cable.
18 Remove securing devices of rudder and rudder pedals.
19 Check free travel of rudder.
