CHAPTER 28
PAGE 9
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
28-10-01 Rear Center Tank
Removal/Installation
1 Remove the main fuselage cover as per Chapter 51.
2 Drain the fuel system per Chapter 12.
3 Remove the instrument panel as per Chapter 31.
4 Remove the torque tube as per Chapter 27.
5 Remove one rudder pedal as per Chapter 27.
6 Remove smoke tank as per Chapter 96.
7 Disconnect the electrical bonding and the fuel quantity trans-
ducer wiring from the rear center tank.
8 Disconnect the fuel and vent lines from the rear center tank.
9 Remove the bottom hose fitting from the rear center tank.
N O T I C E Prevent the drain tube of the GRP tank shell from
breaking when handling the center tank.
10 Remove the metal attachment belts with the rubber stripes.
11 Remove the rear center tank through the cockpit.
12 Install in reverse sequence of removal.
28-10-02 Front Center Tank
Removal/Installation
1 Remove the rear center tank as per Chapter 28-10-01.
2 Remove the wing as per Chapter 57.
3 Remove the battery as per Chapter 24.
4 Remove the acro tank as per Chapter 28-10-03
PAGE DATE: 29. May 2009
