CHAPTER 28
PAGE 10
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
5 Disconnect the electrical bonding and the fuel quantity trans-
ducer wiring from the front center tank.
6 Disconnect the fuel and vent lines from the front center tank.
7 Remove the bottom hose fitting from the front center tank.
N O T I C E Prevent the drain tube of the GRP tank shell from
breaking when handling the center tank.
8 Remove the metal attachment belts with the rubber stripes.
9 Remove the front center tank through the cockpit.
10 Install in reverse sequence of removal.
28-10-03 Acro Tank
Removal/Installation
1 Remove the main fuselage cover and RH side cover as per
Chapter 51.
2 Remove the rear center tank as per Chapter 28-10-01.
3 Disconnect the electrical bonding from the acro tank.
4 Disconnect the fuel and vent lines from the acro tank.
5 Remove the metal attachment belts with the rubber stripes.
6 Remove the acro tank.
7 Install in reverse sequence of removal.
MAINTENANCE PRACTICES
PAGE DATE: 29. May 2009
