CHAPTER 28
PAGE 21
MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 16. June 2008
MAINTENANCE PRACTICES
Figure 9 Gascolator Removal/Installation
28-20-03 Electrical Boost Pump
Removal/Installation
1 Position the fuel selector to "OFF".
2 Drain the forward fuel system using the gascolator drain.
3 Disconnect the plug and the fuel lines on the boost pump.
4 Loosen the clamping device screws (1).
To Next Page
