MAINTENANCE MANUAL EXTRA 300/SC
CHAPTER 33
PAGE 4
PAGE DATE: 1 August 2014
33-40-00 EXTERIOR
33-40-10 LED Strobe Light System
Refer to Figure 1. The LED strobe lights are installed on both
wing tips.
The wiring is routed through an aluminium tube inside the
wing and along the left resp. right upper longeron to the
instrument panel.
The circuit breaker switch is located on the instrument panel
(see Figure 2 of Chapter 31).
