MAINTENANCE MANUAL EXTRA 300/SC
CHAPTER 33
PAGE 5
PAGE DATE: 1 August 2014
33-40-11 LED Strobe Light
Removal/Installation
Refer to Figure 1.
1 Power down the LED strobe lights.
2 Remove the wing tip cover attachment bolts (3).
3 Pull out the wing tip cover plate some centimeters.
4 Remove the LED strobe light attachment bolts (1).
5 Disconnect the electrical wiring.
6 Remove the LED strobe light.
7 Install in reverse sequence of removal after applying Sili-
con between the wing tip cover and the LED strobe light.
