MAINTENANCE MANUAL EXTRA 300/SC
PAGE DATE: 1. August 2014 CHAPTER 55
PAGE 2
Table of Contents
Chapter Title
Chapter 55
55-00-00 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
55-10-00 HORIZONTAL STABILIZER . . . . . . . . . . . . . . . . . . . 4
Figure 1 Horizontal Stabilizer Removal/Installation . . . . . . . . . 5
Figure 2, Sheet 1 Layer Sequence Horizontal Stabilizer (Bottom) . . . . . 6
Figure 2, Sheet 2 Layer Sequence Horizontal Stabilizer (Top) . . . . . . . . 7
Figure 3, Sheet 1 Layer Sequence Elevator (Bottom) . . . . . . . . . . . . . . . . 8
Figure 3, Sheet 2 Layer Sequence Elevator (Top) . . . . . . . . . . . . . . . . . . 9
55-30-00 VERTICAL STABILIZER . . . . . . . . . . . . . . . . . . . . . 10
Figure 4 Vertical Stabilizer Removal/Installation . . . . . . . . . . 11
Figure 5, Sheet 1 Layer Sequence Vertical Tail (up tp SN SC024) . . . . . 12
Figure 5, Sheet 2 Layer Sequence Vertical Stabilizer (from SN SC025) 13
Figure 5, Sheet 3 Layer Sequence Rudder (from SN SC025) . . . . . . . . . 14
