CHAPTER 73
PAGE 18
MAINTENANCE MANUAL EXTRA 300SC
PAGE DATE: 1. August 2014
Figure 8 Fuel Pressure Sense Line
73-30-11 Fuel Pressure Gauge
Removal/Installation
Refer to chapter 31.
73-30-12 Sense Line
Removal/Installation
1 Remove cowling per chapter 71.
2 Remove clamps.
N O T I C E Pick up spilling fluid, when disconnecting a sense line.
3 Disconnect the sense line from the fitting.
