CHAPTER 78
PAGE 8
MAINTENANCE MANUAL EXTRA 300SC
PAGE DATE: 1. August 2014
78-10-12 Muffler
Replacement
1 Remove exhaust system per chapter 78-10-10.
2 Loosen the clamps on the muffler side flanges and remove
the left and right collector tubes.
3 Replace muffler and reinstall in reverse sequence of
removal.
78-10-13 Gasket
Replacement
1 Remove exhaust system per chapter 78-10-10.
2 Replace gaskets.
3 Reinstall exhaust system in reverse sequence of removal.
78-10-14 Heat Shield
Replacement
Refer to figure 4.
1 Remove cowling per chapter 71.
2 Remove heat shield worm drive hose clips.
3 Replace heat shield (pointing directly to cowling).
4 Reinstall in reverse sequence of removal.
