CHAPTER 78
PAGE 10
MAINTENANCE MANUAL EXTRA 300SC
PAGE DATE: 1. August 2014
Side View
Slip joints
Exhaust pipes
Exhaust Support
System
Smoke Oil
Injection Nozzle
Gaskets
Slip joints
End pipe
FWD
Figure 2 Alternative Exhaust System Sky Dynamics 6 in 1
Trouble Shooting
Trouble Possible Cause Remedy
Cylinder outside sooted Gasket defective Replace gasket per
Ch. 78-10-23.
Exhaust flange bent Replace exhaust pipe per
Ch. 78-10-21.
N O T E The use of new gaskets is recommended whenever re-
placing or reinstalling exhaust system components.
Removal
1 Remove upper and lower engine cowling per Ch. 71.
