Section 1 Pilot’s Operating Handbook
General EXTRA 500
1.2.c Fonts
Different fonts are used to mark various parts of equipment and
can be found in a similar style on the aircraft.
Sans serif, semi-bold characters correspond to panel areas,
switches, circuit breakers, rheostats, handles or levers and to the
related positions (e.g.
FUEL PUMP 1 or IGN OFF). Circuit
breakers and rheostats are additionally marked as such (e.g.
FUEL-P-1 circuit breaker, -TEMP CTRL- rheostat).
Sans serif, semi-bold inverted characters on grey background
correspond to annunciator lights on the annunciator panel (e.g.
FLAPS or FUEL TRANS LEFT). The color of the respective
annunciator light is indicated (where applicable) by the
following abbreviations:
r = red (warning)
y = yellow (caution)
g = green (safe operation)
Special inverted characters on grey background correspond to
indications on digital displays (e.g.
6ood or 40.2).
