Section 5 Pilot’s Operating Handbook
Performance EXTRA 500
Dynamic pressure dependant temperature rise
0
1
2
3
4
5
6
7
8
0 50 100 150 200 250
KIAS
Temperature rise [°C]
Due to dynamic pressure, the IAT indication is higher
and dependant on altitude and airspeed. To get the
correct static temperature, substract the temperature rise
from the indication.
SL
5000 ft
10000 ft
15000 ft
20000 ft
25000 ft
The recovery factor of the IAT sensor is k=0.50 [-].
Example: The IAT indicator shows a
temperature of 4 °C in 6000 ft.
The KIAS is 175.
The temperature rise is: 2.4 °C
And the static outside temperature
4 - 2.4 = 1.6 °C
Figure 5-2
IAT-OAT Conversion
Figure 5-2 b
