Section 5 Pilot’s Operating Handbook
Performance EXTRA 500
CONDITIONS:
TAKEOFF DISTANCE
Takeoff Rotation Takeoff Rotation
Landing gear down and flaps 15
WeightSpeed WeightSpeed
2030 RPM - BLEED 2
LBS KIAS KG KIAS
111 % Torque or 810 Deg.CTOT
4696 71,0 2130 71,0
4600 70,6 2100 70,7
Paved, Level, DryRunway
4400 69,6 2000 69,7
Zero Wind
4200 68,7 1905 68,7
4000 67,7 1900 68,6
1800 67,6
NOTES: Decrease distances 10% for each 10 knots headwind.
3900 67,3 1769 67,3
For operation with tailwind up to 10 knots, increase distances by 10% for each 2.5 knots.
3800 66,8 1700 66,6
For operationonadry, grass runway, increase distances by40% of the "ground roll" figure.
3600 65,9 1600 65,5
3417 65,0 1550 65,0
SPEED ISA -20 C ISA -10 C ISA ISA +10 C I
SA +20 C ISA +30 C
WEIGHT AT PRESS
LBS 50 FT ALT TOTAL TOTAL TOTAL TOTAL TOTAL TOTAL
(KG) KIAS FT GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
GRND
TOCLEAR
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
ROLL
50 FT OBS
3900 74 S.L. 780 1280 800 1310 815 1335 830 1365 850 1395 950 1560
(1769) 1000 810 1325 825 1350 845 1385 850 1400 905 1480 1005 1650
2000 835 1370 850 1400 860 1420 875 1445 955 1565 1065 1745
3000 860 1415 880 1445 905 1475 915 1505 1010 1660 1125 1850
4000 890 1460 910 1490 930 1525 975 1595 1075 1760 1195 1955
5000 915 1505 940 1540 960 1575 1030 1690 1140 1865 1265 2075
6000 945 1550 970 1585 985 1620 1090 1800 1205 1980 1340 2195
7000 975 1595 1000 1635 1030 1695 1160 1910 1280 2100 1420 2325
8000 1000 1640 1030 1680 1095 1800 1230 2030 1355 2225 1500 2460
9000 1030 1685 1090 1780 1175 1930 1310 2150 1440 2360 1585 2605
10000 1070 1755 1165 1910 1270 2085 1390 2275 1525 2500 1680 2750
Fig 5-5
Takeoff (Sheet 3 of 4)
