Pilot’s Operating Handbook Section 5
EXTRA 500 Performance
RANGE PROFILE
45 MINUTES RESERVE
172 GAL, (652 L), (1166 LB) USABLE FUEL
CONDITIONS: 4696 LBS (2130 KG)
Standard Temperature
Zero Wind
NOTE: Range includes warmup, taxi, takeoff, max. power climb,
descent plus 45 minutes reserve at cruise power.
Pressure RANGE (NM)
Altitude
(FT)
92% 90% 85% 80% 70% 60% 50% 40%
0 786 794 816 841 889 928 950 958
2000 817 825 848 873 925 968 995 1008
4000 846 855 880 907 961 1008 1042 1062
6000 871 882 909 939 998 1051 1090 1117
8000 894 905 934 967 1033 1093 1140 1172
10000 914 925 956 991 1065 1135 1191 1230
12000 940 950 981 1016 1095 1173 1238 1285
14000 977 1005 1040 1122 1209 1284 1341
16000 1021 1056 1143 1239 1327 1396
18000 1058 1154 1262 1365 1448
20000 1153 1281 1398 1498
22000 1297 1421 1542
24000 1336 1442 1580
25000 1450 1588
Indicates performance outside the engine limitations.
Data is provided for extrapolation purposes.
Figure 5-10
Range
26. January 2011
5-39
