Extra EA 500 - Page 221

Pilot’s Operating Handbook Section 5
EXTRA 500 Performance
BALKED LANDING CLIMB PERFORMANCE
Conditions: Landing gear down and flaps 30
2030 RPM -BLEED 2
CLIMB SPEED 80 KIAS
111 % Torque or 810 Deg. C TOT
RATE OF CLIMB (FT/MIN)
RATE OF CLIMB (FT/MIN)
Pressure 3900 LB (1769 KG)
Pressure 4696 LB (2130 KG)
Altitude
Altitude
(Feet) ISA ISA ISA ISA ISA (Feet) ISA ISA ISA ISA ISA
-20 C +10 C +20 C +30 C
-20 C +10 C +20 C +30 C
SL 1610 1545 1510 1475 1255
SL 1190 1135 1100 1065 875
1000 1590 1530 1495 1405 1165
1000 1175 1115 1080 1000 800
2000 1575 1510 1475 1305 1070
2000 1160 1100 1065 915 720
3000 1560 1495 1455 1210 980
3000 1140 1080 1045 835 645
4000 1540 1475 1360 1110 890
4000 1125 1065 960 750 565
5000 1525 1460 1245 1015 800
5000 1105 1045 865 670 490
6000 1505 1410 1135 915 705
6000 1090 1005 770 585 410
7000 1490 1270 1025 820 615 7000 1070 885 675 505 335
8000 1470 1130 915 720 525 8000 1055 765 580 420 255
9000 1315 990 800 625 435
9000 925 650 485 335 *
10000 1100 845 690 525
340
10000 750 530 390 255 *
RATE OF CLIMB (FT/MIN) *Denotes conditions where the
Pressure 4200 LB (1905 KG)
balked landing climb gradient
Altitude
can not be maintained
(Feet) ISA ISA ISA ISA ISA
-20 C +10 C +20 C +30 C
SL 1435 1375 1340 1305 1100
1000 1420 1355 1325 1235 1015
2000 1400 1340 1305 1145 930
3000 1385 1320 1285 1055 845
4000 1365 1305 1195 965 760
5000 1350 1280 1090 875 675
6000 1330 1245 985 780 585
7000 1315 1115 885 690 500
8000 1300 985 780 600 415
9000 1160 855 675 510 330
10000 965 725 570 420 245
Example refer to 5.4.d
Figure 5-12
Landing (Sheet 2 of 2)
26. January 2011
5-43
