Pilot’s Operating Handbook Section 6
EXTRA 500 Weight and Balance and Equipment List
Weight and Balance Loading Form (SI units)
Ref Item
Arm
(m)
Weight
(kg)
Moment
(kgm)
1 Basic Empty Weight (refer to figure 6-2)
2 Pilot (Station 2.825 - 2.977)
3 Copilot (Station 2.825 - 2.977)
4
Passenger(s) on Seats 3 + 4 (Station 3.930)
(refer to figure 6-5)
5
Passenger(s) on Seats 5 + 6 (Station 5.050)
(refer to figure 6-5)
6
Baggage (Station 5.750) (Do not exceed max.
weight in baggage compartment of 90 kg).
(refer to figure 6-5)
7
Zero Fuel Weight (sub-total)
(Do not exceed max. zero fuel weight of 1945 kg)
8a
Fuel Loading main compartment
(refer to figure 6-6a)
8b
Fuel Loading auxiliary compartment
(if applicable, refer to figure 6-6b)
9
Ramp Weight (sub-total)
(Do not exceed max. ramp weight of 2130 kg)
10 Less Fuel For Taxiing (refer to figure 6-6)
11
Takeoff Weight
(Do not exceed max. takeoff weight of 2130 kg)
12a
Less Fuel To Destination main compartment
(refer to figure 6-6a)
12b
Less Fuel To Destination auxiliary compartment
(if applicable, refer to figure 6-6b)
13
Landing Weight
Figure 6-4
Weight and Balance Loading Form (Sheet 1 of 2)
26. January 2011 6-13
To Next Page
