Section 6 Pilot’s Operating Handbook
Weight and Balance and Equipment List EXTRA 500
No Item Manufacturer Part No
Weight
[kg]
Arm
[m]
Re-
mark
s/inst.
22 Auto Flight
1 System 55X
Programmer /
Computer
S-Tec 01192-0-37T 1.362 2.400 RS
1 Yaw Amplifier S-Tec 0121-6-2 1.000 6.863 RS
1 Trim Servo S-Tec 0106-2-T3 1.310 6.683 RS
1 Roll Servo S-Tec 0106-R2 1.310 3.200 RS
1 Pitch Servo S-Tec 0108-P4 1.310 6.683 RS
1 Yaw-Servo S-Tec 0106-6-Y9 1.310 6.683 RS
1 Pressure Transducer S-Tec 0111 0.030 9.8 RS
23 Communications
1 Audio panel PS Engineering PMA8000B; 050-890-0402 0.850 2.200 RS
1 Audio panel PS Engineering PMA8000BT; 050-890-0404 0.850 2.200 RA
1 Transponder Becker BXP-6402-1R-(01) 0.680 6.971 RS
1 ELT Artex ME406; 453-6603 1.036 7.650 RS
2 Headset Bose Series X; AHX-04 0.450 2.900 RS
2 Headset Bose Series X; AHX-04 0.450 3.930 O
2 Headset Bose Series X; AHX-04 0.450 5.050 O
1 Microphone Holmco 85-03-04963-04 0.200 2.400 RS
1 Twin Cone Speaker RS 845-308 0.200 3.000 RS
24 Electrical Power
1 Lead Acid Battery Concorde RG-390E/L 28.100 1.750 RS
1 Disconnect PLUG
Battery
Rebling Plastics MS3349-2; 7016-2 0.300 1.800 RS
1 Starter Generator Aircraft Parts
Corp.
200SGL129Q(5)-1 10.000 1.076 RS
1 Generator Control Unit Aircraft Parts
Corp.
GCSG505-21 1.150 1.860 RS
1 Standby alternator B+C BC410-1 2.600 1.000 RS
1 Alternator regulator B+C BC203-2D 0.200 1.700 RS
1 External Power
Connector
Anderson AN2552-3A 0.350 1.750 RS
1 Inverter for
electroluminescent
panels
KGS SD3 0.454 5.000 RS
(1) DC-DC Converter
(24VDC =>12VDC)
Switched Mode SM 2430 0.650 3.400 RS
6-24 26. January 2011
