Extra EA 500 - Page 248

Section 6 Pilot’s Operating Handbook
Weight and Balance and Equipment List EXTRA 500
No Item Manufacturer Part No
Weight
[kg]
Arm
[m]
Re-
mark
s/inst.
29 Hydraulic Power
1 Hydraulic Power Pack Extra EA-5B530 4.250 3.500 RS
30 Ice and Rain protection
1 Deice boot timer BF-Goodrich 3D2991-14 0.200 2.690 RS
2 Ejector flow control
valve (incl. press.
switch)
BF-Goodrich 3D3556-03 0.340 1.900 RS
1 Windshield Heat
Controller
Kissling AT15.2121 0.100 2.950 RS
1 Prop Deice Indicator
(Amperemeter)
UMA N15 1120 030P 01W rev.B 0.050 2.240 RS
31 Indicating/Recording Systems
1 Annunciator Panel
upper
West Coast
Specialities
90-42192-1 0.240 2.240 RS
1 Annunciator Panel
lower
West Coast
Specialities
90-42192-2 0.240 2.240 RS
32 Landing Gear
1 Nose wheel tire Goodyear/McCr
eary/Michelin
5.00-5 6ply 1260lbs 2.153 1.414 RS
1 Nose wheel Cleveland 40-78B 1.191 1.414 RS
2 Main wheel tire (L/H -
R/H)
Goodyear 15x6.00-6 10-ply Tubeless 3.527 4.070 RS
2 Main wheel (L/H -
R/H)
Cleveland 40-96E 3.206 4.070 RS
2 Main wheel brake
(L/H - R/H)
Cleveland /
Extra
30-61B (mod) 1.282 4.170 RS
33 Lights
2 Recognition Light L.
& R.
Whelen 010771125-XX 0.140 3.300 S
1 ACL / NAV Light Left Whelen A 650-PR-28V;
01-0770054-03
0.200 3.800 RS
1 ACL / NAV Light
Right
Whelen A 650-PG-28V;
01-0770054-01
0.200 3.800 RS
1 ACL / NAV Light Tail Whelen A 500AV28;
01-0770024-01
0.100 9.750 RS
1 ACL L. Power Supply
Wing
Whelen A 413A; HDA-CF 14/28V;
01-0770028-05
1.000 3.110 RS
1 ACL L. Power Supply
Tail
Whelen A 490; TCF-14/28V;
01-0267771-00
0.550 7.350 RS
1 Ice Light Whelen 01-0790093-00 0.100 1.730 S
1 Flash Light Mag Lite ML2 0.700 3.400 RS
6-26 26. January 2011
