Extraflame 00227596 - Alarm Memory Reset; Outputs Test

P6
P6
P2
P6
P2
11
FIRMWARE VXX
Ignition plug test
ON/ OFF
Auger test
0.000 ... 4.000
Fumes test
0.00F ON/ OFF
Fan 1 test
OFF..65V....225V
Fan 2 test
OFF..65V....225V
TECHNICIAN MENU
ALARM MEMORY RESET
CONTROLS PROCEDURE
 Press P6 and SET CLOCK will appear.
 Press P2 several times until TECHNIC SET is displayed.
 Press P6.
 Hold key P4 down to reach the reserved code "A0"
 When the code has been reached, conrm by pressing P6
 "GENERAL DATA" will appear
 Press P2 until ALARM MEMORY RESET is displayed.
 Enter pressing P6
 Hold key P4 down to reach code "77" and conrm with P6.
 "DONE" will be signalled on the display to conrm the command
OUTPUTS TEST
CONTROLS PROCEDURE
 Press P6 and SET CLOCK will appear.
 Press P2 several times until TECHNIC SET is displayed.
 Press P6.
 Hold key P4 down to reach the reserved code "A0"
 When the code has been reached, conrm by pressing P6
 "GENERAL DATA" will appear
 Press P2 until OUTPUTS TEST is displayed.
 Enter pressing P6
 Use the P4 or P5 keys to activate - deactivate the various tests, P2 to select
another component and P3 to go back.
 Press P1 to return to the previous menus up to the initial status.
GENERAL DATA
TECHNIC SET
CODE A0
ALARM MEMORY
RESET
GENERAL DATA
TECHNIC SET
CODE A0
INSTALLER
PARAMETERS
OUTPUTS TEST
THE DATA IN THE TABLES ARE FOR ILLUSTRATION PURPOSES ONLY
FROM V3 FIRMWARE NO LONGER AVAILABLE
