ALARMS
DISPLAY EXPLANATION SOLUTION
Indicates the presence of an alarm.
On: indicates the presence of an alarm
O: indicates the absence of alarms
Flashing: indicates the deactivation of the depression sensor.
The alarm can be reset by pressing key 1 for 3 seconds only if the
fumes motor has stopped and if 15 minutes have passed from
displaying the same alarm.
FUMES FAILURE
Fault correlated to the ue gas
exhaust motor.
Check that the fumes motor turns freely.
Control fumes motor and encoder wiring.
Perform the outputs test to check that the encoder/fumes motor
functions.
Replace the fumes motor.
FUMES PROBE
Fault correlated to the fumes probe.
Perform the stove status (status 0) and check whether the
value detected by the probe is read.
Check the wiring.
Replace the fumes probe
ALARM FUMES
OVERTEMPERATURE
The ue gas temperature has
exceeded 310°C
Check pellet ow (see “Pellet feed adjustment”).
Check that the machine is clean, including the ue route.
Do not rest cloths on the machine.
CLEAN
CHECKUP 1  2
1= AT STARTUP
2= AT WORK
The combustion chamber or burn pot
bottom are dirty.
The door is not closed correctly.
The ash drawer is not closed
correctly.
The depression sensor is faulty.
The ue exhaust pipe is blocked.
Incorrect installation
Make sure the holes at the burn pot bottom are completely free.
Check cleanliness of the fumes pipe and the combustion chamber.
Check hermetic door closure.
Check hermetic closure of the ash drawer.
Other restoration operations must be carried out by an authorised
technician.
DEPR ALARM
The mechanical depression sensor
has tripped
Check closure of the door
Check the status of the tube to the silicon sensor
Check cleanliness of the flue
Check the amount of pellets in the feed box
NO
IGNITION
The pellet feed-box is empty.
Pellet feed calibration inadequate.
Incorrect installation
Check for the presence of pellets in the feed-box.
Adjust pellet ow (see “Pellet feed adjustment”).
Check the procedures described in the “Ignition” chapter.
BLACKOUT NO IGN.
No current during the ignition phase.
Check for the presence of pellets in the feed-box.
Regulate the pellet flow.
Check that the machine is clean.
Check that the ign-plug is positioned correctly.
Replace the ign-plug.
Check that there is not too much draught, if this is not the case, lower the
fumes motor in ignition parameter.
NO PELLETS
In the work phase, the t° of the ue
gases has dropped below factory
parameters
Check for the presence of pellets in the feed-box.
Regulate the pellet ow.
COOLING STANDBY
Attempt to release the alarm with
stove still in cooling mode.
Every time the stove displays one of the alarms listed above it will
switch-o automatically.
The stove will block any release attempt during this phase,
showing the alarm itself and ATTE alternately on the display.
The alarm can be reset by pressing key 1 for 3 seconds only if the
fumes motor has stopped and if 15 minutes have passed from
displaying the same alarm.
DEPR SENSOR
DAMAGE
Component disconnected or faulty
Check whether the sensor is disconnected
Check whether the sensor is faulty and replace it if necessary
ALLARME COMANDO
COCLEA
Anomalous functioning
of pellet feeding
Verify the output of the motherboard
BLOCCO COCLEA
abnormal function
motor pellet
Check if the pellet motor turns freely
Check pellet motor wiring and its encoder wiring
Replace the pellet motor
