DISPLAYS
DISPLAY REASON
OFF
Stove o
START
The start phase is in progress
PELLET FEEDING
The feeding of the pellet during the ignition phase is in progress
IGNITION
The ignition phase is in progress
STARTUP
The start phase is in progress
WORK
The normal work phase is in progress
MODULATION
The stove is modulating
BURN POT CLEANING
The automatic burn pot cleaning is in progress.
FINAL CLEANING
When the stove is switched-o, nal cleaning is in progress. The nal cleaning phase lasts about 10
minutes.
STAND BY
Stove o due to temperature reached and in stand-by for re-ignition.
STAND BY EXT
Stove o due to an external thermostat, waiting for re-ignition
COOLING STANDBY
A new ignition is attempted when the stove has just been switched-o
When the stove switches o, it is necessary to wait until complete fumes motor switch o and then clean
the burn pot.
The stove can only be re-ignited when these operations have been performed.
COOLING STDBY
BLACK OUT
The stove is cooling due to black out
LOW
Room thermostat set at minimum value.
In this way the stove only works at 1st power independently from the power set. To escape this function
just raise the room temperature using button 4 and then key 2.
HOT
Set room thermostat set at maximum value.
The stove works at set start, without ever modulating. To escape this function just lower the set
temperature using key 4 and then key 1.
