ENSURE THAT THE ASH IS COMPLETELY COLD BEFORE EMPTYING IT IN A SPECIAL CONTAINER.*THE “CHIMNEY SWEEP” BIN IS AN
ACCESSORY THAT CAN BE REQUESTED FROM THE COMPANY. FOR FURTHER INFORMATION, CONTACT INFOEXTRAFLAME.IT.
THE IMAGES ARE FOR ILLUSTRATION PURPOSES ONLY.
A
Fumes motor
(disassembly and
cleaning and fumes
pipe), new silicone in
envisioned points

B
Gaskets
inspections, ash drawer
and door (replace them
and apply silicone where
envisioned)

C
Combustion chamber
(total cleaning of the
entire chamber)
and ign-plug holder
tube

D
Feed box (complete
emptying and cleaning).

E
Room air fan
disassembly and
removal of dust and
debris of any pellets

F
Check air intake pipe
and cleaning of the ow
sensor

MAINTENANCE
AUTHORISED MAINTENANCE TECHNICIAN
A
B
C
D
EF
