9
WHAT IS THE PELLET?
Chapter 2
If installation has been performed using this optional kit, the insert can be extracted or, more comfortably,
use the appropriate lateral chute whenever a relevant opening has been made in the covering of the
appliance.
FRONT PELLET FEEDING OPTIONAL KIT
The use of this optional kit allows to feed the pellets into the feed-box from the front without extracting
the ue, therefore without switching it o .
First, remove the front, upper frame by unhooking it from the 2 lateral frames: to do this, lift it by about 10 mm
FRONT UPPER FRAME
and then pull it towards yourself.
The frame must be picked-up using protection for the hands as it could have over-heated during functioning.
Take the supplied re irons, attach them to the slots in the drawer and pull to maximum extension.
gure 2.1
gure 2.2 gure 2.3 gure 2.4
