12. STOVE OPERATION
12.1 Normal operation
Once the stove is lit, you can adjust the heat setting using buttons 4 and 5. Pressing button 4
decreases the heat setting and hourly pellet consumption; pressing 5 increases them. In addition
to the feed rate, the room temperature can be set directly from the control panel. The stove
adjusts itself automatically in relation to the warm air ventilation.
The contents of the tank should be monitored to prevent the stove going out due to a lack of fuel.
ATTENTION!
1. The cover of the pellet container must always be kept closed except when
loading fuel.
2. The sacks of pellets must be kept at least 1.5 metres away from the stove.
3. The tank should always be kept at least half full.
4. Before refilling, make sure that the appliance is switched off.
12.2 Shutdown
Press button 1 for three seconds.
When the three seconds have elapsed, the stove automatically starts the shutdown stage, cutting
off the pellet feed. Display D1 shows the message “OFF” .
The exhaust motor will continue to run until the temperature of the stove has decreased
sufficiently.
12.3 Remote control
The heat setting, the room temperature, and automatic start/stop of the stove can be remote
controlled.
S = Light that indicates which keys have
been pressed.
Correspondence of display keys with
remote control keys
1 = p3+p5
2 = p2
3 = p3
4 = p4
5 = p5
