Extraflame LUCREZIA IDRO - 16.2 Brazier Bracket Removal; 16.3 Brazier Positioning

Page
36
16.2 Brazier bracket
Before lighting the stove, make sure that the bracket shown in the figure has been removed.
16.3 Positioning the brazier
The two pieces shown in the figure, which make up the brazier, are situated inside the
pellet tank. Before lighting the stove, position them as shown in the photographs.
Remove the screw
Remove the bracket
