48 Door safety micro switch
49 Secondary output terminal (optional)
50 Neutral terminal
51 Neutral terminal
52 Primary output terminal (optional)
53 Earth terminal
54 Secondary external contact input terminal (optional)
55 “Common” terminal for inputs
56 Primary external contact input terminal (optional)
57
58
Priority external contact input terminal (optional)
