b. Pull the blue release latches on the chassis rails towards the front and slide the switch
into the frame.
Note:
After you install the switch in a rack, slide it out until the lock (shown above) engages.
To slide the switch back into the rack, push the blue locks on the chassis rails towards
the back and slide the switch into the frame.
12. Connect power and network connections to the switch.
Installing the switch in an equipment rack
March 2020 Installing the VSP 7200 Series 69
