ISM 824 Integration Scaling Multiswitcher • SIS
™
Programming and Control
4-10
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web) (host to switcher)
Response (switcher to host)
Additional description
Read output grouping
EO}
X4%
1
X4%
2
X4%
3
....X4%
8
]
One
X4%
entry for each
output, starting from output 1, 8 is the maximum output.
N The group assigned
X4% must be 1, 2, 3, 4, or 0 (not grouped)
Video mute
Enable blanking
X@*1B
X@%2A 1B X@
Vmt
1
]
Blanks selected output.
Disable blanking
X@*0B
X@%2A 0B X@
Vmt0
]
Displays selected output.
View
X@B X@B X1)]
View the blanking status.
Audio mute
Mute on
X@*1Z
X@%2A 1Z
X@
Amt
1]
Mute selected output.
Mute off
X@*0Z
X@%2A 0Z
X@
Amt
0]
Unmute selected output.
View
X@Z X@Z X1)]
View mute status.
Volume control
Specific vlume
X@*X3$V
X@%2A X3$V OutX@
*Vol
X3$]
Set volume to
X3$
for output
X@
.
Increment
X@+V X@+V OutX@
*Vol
X3$]
Increase volume.
Decrement
X@-V X@-V OutX@
*Vol
X3$]
Decrease volume.
View
X@V X@V X3$]
View current volume setting.
RGB delay time
Delay on
3*
X@*X3&#
3%2A
X@%2AX3&# X@
Dly
X3&]
Set RGB delay.
View setting
3*
X@# 3%2AX@# X3&]
View RGB delay setting.
Audio gain and attenuation
Specific gain
X!*X3@G
X!
%2A
X3@
G
In
X!•
Aud
X3!]
Set input
X!
gain to
X3!
.
Set attenuation
X!*X3#g
X!
%2A
X3#
g
In
X!•
Aud
X3!]
Set input
X!
attenuation
to
X3#
.
Increment
X!+G/g X!+G/g
In
X!•
Aud
X3!]
Increase input
X!
audio level
to
X3!
.
Decrement
X!-G/g X!-G/g
In
X!•
Aud
X3!]
Lower input
X!
audio level
to
X3!
.
View
X!G/g X!G/g X3!]
View audio level of input
X!.
Global video mute
Global RGB mute 1*B 1%2A B
0Vmt1
]
Mute all video outputs.
Global RGB unmute 0*B 0%2A B
0Vmt0
]
Unmute all video outputs.
Global audio mute
Global audio mute 1*Z 1%2A Z
0Amt1
]
Mute all audio outputs.
Global audio unmute 0*Z 0%2A Z
0Amt0
]
Unmute all audio outputs.
