Symbol Definitions
]
= CR/LF (carriage return and line feed) (hex 0D 0A)
}
= Soft carriage return (no line feed)
• = Space
E
= Escape key (hex 1B)
X!
= On and off (enable and disable)
0 = Off or disabled
1 = On or enabled
X@
= Extender unit part number:
Transmitter: 60-1471-12
Receiver: 60-1471-13
HID Only Transmitter: 60-1539-12
HID Only Receiver: 60-1539-13
AAP Transmitter, black: 60-1472-12
AAP Transmitter, white: 60-1472-13
AAP Receiver, black: 60-1472-22
AAP Receiver, white: 60-1472-23
Decorator-style Transmitter: 60-1473-13
Decorator-style Receiver: 60-1473-23
X#
= IP address (Default is 192.168.254.254.)
X$
= Subnet mask (Default is 255.255.0.0.)
X%
= Gateway IP address (Default is 0.0.0.0.)
X^
= Port number for Config port (Default is 6137.)
NOTE: Unless otherwise indicated, commands are not case-sensitive.
USB Extender Plus Series • Remote Configuration and Control 24
