Extron electronics USB Extender Plus Series - Command and Response Table for SIS Commands

Command and Response Table for SIS Commands
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Information Requests
Request part number
N
X@ ]
Show the extender part number
X@
.
For
X@
:
Transmitter: 60-1471-12
Receiver: 60-1471-13
HID Only Transmitter: 60-1539-12
HID Only Receiver: 60-1539-13
AAP Transmitter, black: 60-1472-12
AAP Transmitter, white: 60-1472-13
AAP Receiver, black: 60-1472-22
AAP Receiver, white: 60-1472-23
Decorator-style Transmitter: 60-
1473-13
Decorator-style Receiver: 60-1473-
23
Query firmware version
Q
n.nn
]
Show the firmware version, expressed to
the second decimal place.
Example:
Q
1.01
]
The unit firmware version is 1.01.
Query firmware version
and build
*Q
n.nn.nnnn
]
Show firmware version and build number.
Peripheral Emulation (Transmitters Only)
NOTE: These commands can be issued only to the transmitter.
Set peripheral emulation
E
E
X!
USBC
}
Usbc E
X! ]
Set peripheral emulation for the
USB Extender Plus T to
X!
. For
X!
:
0 = disabled
1 = enabled (default)
View peripheral
emulation
E
E USBC
} X! ]
Network Pairing
Enable 1:N network
pairing
E
N
X!
USBC
}
Usbc N
X! ]
Enable or disable pairing of the transmitter
with receivers via the network. For
X!
:
0 = pairing disabled
1 = pairing enabled (default)
View 1:N network
pairing
E
N USBC
} X! ]
Resetting
NOTE: This command must be issued to both the transmitter and the receiver.
Reset device settings to
factory defaults
E
ZXXX
}
Zpx
]
Reset the extender to factory default
values while retaining pairing and IP
settings.
Absolute system reset
E
ZQQQ
}
Zpq
]
Reset all extender settings to factory
defaults except firmware version.
Upload Firmware
Upload firmware
E
UPLOAD
}
...go
Upl
]
Upl
]
is displayed after the upload is
complete.
USB Extender Plus Series • Remote Configuration and Control 25
