3XTP II CrossPoint Series • Introduction
The XTP II CrossPoint Series matrix switchers are assembled from
user-installed and hot-swappable input and output boards. The
Input and Output Boards table on the previous page identies the
types of input boards and output boards currently available, each
of which can receive (input boards) or output (output boards) up to
four signals (see Inputs and Outputs on page 5 for details).
The XTP II CrossPoint 1600 can support up to four input boards
and four output boards of any of the type listed in the Input and
Output Boards table, for a total of 16 inputs and 16 outputs.
The XTP II CrossPoint 3200 can support up to eight input boards
and eight output boards of any of the type listed in the Input and
Output Boards table, for a total of 32 inputs and 32 outputs.
The XTP II CrossPoint 6400 can support up to 16 input boards and
16 output boards of any of the type listed in the Input and Output
Boards table, for a total of 64 inputs and 64 outputs.
The matrix switcher can be remotely controlled via an Ethernet
LAN port, serial port, or USB port connection using either the
Extron XTP System Conguration Software or SIS commands.
Endpoint Configuration
In an XTP system, the transmitters connected to the input boards
and the receivers connected to the output boards are known as
"endpoints."
When you congure an XTP system (consisting of an
XTP II CrossPoint Series matrix switcher and its connected
endpoints), connect a computer to the matrix switcher and
congure the endpoints from the matrix switcher.
Do not connect the computer directly to the endpoint for
conguration when it is part of an XTP system.
Swapping Board and Endpoints
When you replace an input board, an output board, or an endpoint,
the matrix switcher automatically applies settings to the new
device. If the stored settings are incompatible with the newly
installed device, the matrix switcher applies a default conguration.
