Extron electronics XTP II CrossPoint Series Setup Guide

46 XTP II CrossPoint Series • Remote Control
XTP System Configuration Program
Another way to operate the matrix switcher is via the Windows
®
-
based XTP System Conguration software. For details on installing
and operating the program, see the XTP System Configuration
Software Help le.
NOTES:
• If your Ethernet connection to the matrix switcher is
unstable, try turning off the proxy server in your web browser.
In Microsoft Internet Explorer, click Tools > Internet
Options > Connections > LAN Settings, uncheck the Use
a proxy server... box, and then click OK.
• For details on operating the matrix switcher via HTML pages,
see the "HTML Operation" section in the XTP II CrossPoint
Series User Guide.
1. Start the web browser program.
2. Click tin the Address eld.
3. Enter the Matrix IP address in the Address eld.
NOTE: 192.168.254.254 is the factory-specified default
value for this field.
4. Press the keyboard <Enter> key. The matrix switcher checks
whether it is password-protected.
If the matrix switcher is not password-protected, it checks
and downloads the HTML start-up page. The matrix switcher is
ready for operation via HTML remote control.
If the matrix switcher is password-protected, it downloads
the Windows Security dialog box (see gure 11).
Figure 11. Windows Security Dialog Box
NOTE: A User name entry is not required.
