38 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit to Endpoint)
Response (Endpoint to Unit to Host)
Additional Description
List Digital Sync Validation Processing (DSVP)
List sync of all inputs
0LS
X2%
1
X2%
2
X2%
3
...
X2%
n
]
16, 32, or 64 (
n
)
X2%
s; each is the signal status of an
input, starting from input 1.
Example (XTP II CrossPoint 3200):
0LS
Input:
Response Status:
no input detected
input detected
1 2345
6
732
0 0 0 1 1 1 0 . . . 0
HDCP status
View input HDCP status
E
I
X!
HDCP
} X*]
View HDCP status of all inputs
E
I*HDCP
} X*
1
X*
2
X*
3
...
X*
n
]
16, 32, or 64 (
n
)
X*
s; each is the HDCP status of an
input, starting from input 1.
NOTE:
X!
= Input number 01 – 16, 32, or 64
X*
= HDCP status (for inputs) 0 = no source connected
1 = Source is HDCP-compliant 2 = Source is not HDCP compliant X2%
= Signal detection status 0 = no input connected 1 = input connected
