Extron electronics XTP II CrossPoint Series Setup Guide

40 XTP II CrossPoint Series • Remote Control
Command SIS Command
(Host to Unit to Endpoint)
Response (Endpoint to Unit to Host)
Additional Description
Audio mutes
Audio mute, HDMI and S/PDIF
X@
*1Z Amt
X@
*1
]
Mute output
X@
embedded digital (audio off).
Audio mute, analog
X@
*2Z Amt
X@
*2
]
Mute output
X@
analog (analog audio off).
Audio mute, both
X@
*3Z Amt
X@
*3
]
Mute all output
X@
audio (digital and analog audio off).
Audio unmute
X@
*0Z Amt
X@
*0
]
Unmute output
X@
(digital and analog audio on).
Read audio mute
X@
Z
X1)]
1 = mute on, 0 = mute off.
Global audio mute, HDMI and S/PDIF
1*Z
Amt1
]
Mute all embedded digital audio outputs.
Global audio mute, analog
2*Z
Amt2
]
Mute all analog audio outputs.
Global audio mute, both
3*Z
Amt3
]
Mute all embedded digital and analog audio outputs.
Global audio unmute
0*Z
Amt0
]
Unmute all audio outputs.
View video and audio mutes
View output mutes
E
VM
}
X3#
1
X3#
2
...
X3#
n
]
Each
X3#
response is the mute status of an output,
starting from output 1. n = either 16, 32, or 64.
Example : (XTP II CrossPoint 3200)
E
VM
}
Audio is muted on outputs 2 and 3, video on output 5, and video and audio on output 26. All other outputs are unmuted.
Mut02201000000000000000000003000000
]
NOTE:
X@
= Output number 01 – 16, 32, or 64
X1)
= Mute 0 = off (unmuted) 1 = on (muted)
X3#
= Video and audio mute 0 = no mute 1 = video mute 2 = audio mute 3 = video and audio mute
