GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MODEL: RXV FREEDOM™
TYPE: GASOLINE POWERED PERSONAL GOLF CAR
MODEL YEAR: 2016
Part No:. 638543G01
Engine: 13.5 hp (10.1 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
z
Valve Train: Overhead valve z Fuel System: Fixed float bowl with remote pulse fuel pump
z
Lubrication: Pressurized oil system, spin-on oil filter z Ignition: Electronic spark/magneto
z
Balancer: Internal counter rotating balance shaft z Air Cleaner: Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 CCA, 60 minute reserve)
Drive Train: Automatic, continuously variable transmission (CVT)
Brakes: Dual rear wheel mechanical self-adjusting drum brakes. Single point park brake release with self-compensating system
Transaxle: Differential with helical gears, ground speed governor, forward/reverse
Body Protection: 360° energy transfer bumpers maximize vehicle protection from minor impact
Dimensions Performance
Overall Length 94.5 In (240 cm) Seating Capacity 2 Person
Overall Width 47.0 in (119 cm) Dry Weight 697 lb (316 kg)
Overall Height (No Canopy) 45.7 in (116 cm) Curb Weight 747 lb (339 kg)
Overall Height (With Canopy) 68.5 in (174 cm) Vehicle load capacity 800 lb (360 kg)
Wheel Base 65.7 in (167 cm) Outside Clearance Circle 19.0 ft (5.8 m)
Front Wheel Track 35.5 in (90 cm) Intersecting Aisle Clearance N/A
Rear Wheel Track 38.0 in (97 cm) Speed (Level Ground) 19 mph ± 0.5 mph (31 kph ± 0.8 kph)
Gnd Clearance @ Differential 3.3 in (8 cm) Towing Capacity 3 E-Z-GO Golf Cars with approved tow bars
Vehicle Power Steering & Suspension
Power Source 4 Cycle 24.5 cu in (401 cc) Steering Double Ended Rack & Pinion
Valve Train Single Cylinder OHV Front Suspension Independent A-Arm Coil Over Shock
Horsepower (kW) 13.5 hp (10.1 kW) Exceeds SAE J1940 Std. Rear Suspension Mono-Leaf Springs With Hydraulic Shocks
Electrical System Starter/Generator. Solid State Regulator Brake Rear Wheel Mechanical Self-Adjusting Drums
Batteries (Qty, Type) One, 12 Volt Maintenance Free Parking Brake Self-compensating, single point engagement
Key or Pedal Start Pedal Front Tires 18 x 8.50 - 8 (4 Ply Rated)
Industrial Rated Dry Filter with Remote Intake Rear Tires 18 x 8.50 - 8 (4 Ply Rated)
Pressurized Oil System Body & Chassis
Frame Welded Steel. DuraShield™ powder coat
Body & Finish Injection molded TPO
Standard Color Forest Green
Spin On
Air Cooled
5. Gallon (23.1 L) HDUO\SURGXFWLRQtank
*DOORQ/ODWHSURGXFWLRQWDQN
Continuously variable transmission(CVT)
CE Noise, Vibration & Harshness
Noise 6RXQGSUHVVXUHFRQWLQXHG$ZHLJKWHGG%D
Vibration, WBV
Highest value of weighted acceleration less than 2.5 m/s²
Air Cleaner
Lubrication
Oil Filter
Cooling System
Fuel &DSDFLW\
)XHO&DSDFLW\
Drive Train
TransaxleGear
SelectionRear
Axle Ratio
'LIIHUHQWLDOZLWKKHOLFDOJHDUV
)RUZDUG5HYHUVH
)RUZDUG5HYHUVH
Vibration, HAV
Highest value of weighted acceleration less than 2.5 m/s²
Uncertainty of measurement is 0.98 m/s². Measurement methods were applied
per ISO 2631 & ISO 5349 standards under conditions of typical vehicle surfaces.
Some items shown may be optional equipment
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW

Ezgo RVX Specifications

General

Brand	Ezgo
Model	RVX
Category	Utility Vehicle
Language	English
