GENERAL SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
15
Owner’s Guide
MODEL: SHUTTLE™ 2+2 RXV
TYPE: GASOLINE PERSONNEL CARRIER
MODEL YEAR: 2016
Part No:. 638545G01
Engine:
13.5 hp (10.1 kW) Exceeds SAE J1940 Standard, 4 cycle, 24.5 ci (401 cc) single cylinder, air-cooled by Kawasaki
z Valve Train: Overhead valve z Fuel System: Fixed float bowl with remote pulse fuel pump
z Lubrication: Pressurized oil system, spin-on oil filter z Ignition: Electronic spark/magneto
z Balancer: Internal counter rotating balance shaft z Air Cleaner: Replaceable dry cartridge
Electrical: Starter/Generator, solid-state regulator, 12 Volt maintenance free battery (425 CCA, 60 minute reserve)
Drive Train:
Automatic, continuously variable transmission (CVT)
Brakes: Dual rear wheel mechanical self-adjusting drum brakes. Automatic single point park brake release with self-compensating system
Transaxle: Differential with helical gears, ground speed governor, forward/reverse
Body Protection: 360° energy transfer bumpers maximize vehicle protection from minor impact
Dimensions Performance
Overall Length 105.5 in (268 cm) Seating Capacity 4 Person
Overall Width 47.0 in (119 cm) Dry Weight 790 lb (360 kg)
Overall Height (No Canopy) 45.7 in (116 cm) Curb Weight 850 lb (385 kg)
Overall Height (With Canopy) 74.0 in (188 cm) Vehicle load capacity 720 lb (325 kg)
Wheel Base 65.7 in (167 cm) Outside Clearance Circle 19.0 ft (5.8 m)
Front Wheel Track 35.5 in (90 cm) Intersecting Aisle Clearance N/A
Rear Wheel Track 38.0 in (97 cm) Speed (Level Ground) 14 mph ± 0.5 mph (23 kph ± 0.8 kph)
Gnd Clearance @ Differential 3.3 in (8 cm) Towing Capacity N/A
Vehicle Power Steering & Suspension
4 Cycle 24.5 cu in (401 cc) Steering Double Ended Rack & Pinion
Front Suspension
Independent A-Arm Coil Over Shock
Rear Suspension Multi-Leaf Spring with Hydraulic Shocks
Brake
Rear Wheel Mechanical Self-Adjusting Drums
Parking Brake Self-compensating, single point engagement
Front Tires 18 x 8.50 - 8 (4 Ply Rated)
Rear Tires 18 x 8.50 - 8 (4 Ply Rated)
Body & Chassis
Frame Welded steel. DuraShield™ powder coat
Body & Finish Injection molded TPO
Standard Color
Forest Green
CE Noise, Vibration & Harshness
Noise
Sound pressure; continued A-weighted ≤ 70 dB(a)
Vibration, WBV
Highest value of weighted acceleration less than 2.5 m/s²
Power Source
Valve Train
Horsepower (kW)
Electrical System
Batteries (Qty, Type)
Key or Pedal Start
Air Cleaner
Lubrication
Oil Filter
Cooling System
Fuel &DSDFLW\
)XHO&DSDFLW\
Drive Train
Transaxle
Gear SelectionRear
Axle Ratio
Single Cylinder OHV
13.5 hp (10.1 kW) Exceeds SAE J1940 Std.
Starter/Generator. Solid State Regulator
One, 12 Volt Maintenance Free
Pedal
Industrial Rated Dry Filter
Pressurized Oil System
Spin On
Air Cooled
5. Gallon (22.1 L) HDUO\SURGXFWLRQtank
*DOORQ/ODWHSURGXFWLRQWDQN
Continuously variable transmission (CVT)
Differential with helical gears
Forward - Reverse
11.42:1 (Forward) 15.78:1 (Reverse)
Vibration, HAV
Highest value of weighted acceleration less than 2.5 m/s²
Uncertainty of measurement is 0.98 m/s². Measurement methods were applied
per ISO 2631 & ISO 5349 standards under conditions of typical vehicle surfaces.
Some items shown may be optional equipment
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW

Ezgo RVX Specifications

General

Brand	Ezgo
Model	RVX
Category	Utility Vehicle
Language	English
