INTRODUCTION
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
21
Owner’s Manual
INTRODUCTION
CONTROLS AND INDICATORS
Vehicle controls and indicators consists of:
1. Key Switch
2. Fuel Gauge (if equipped)
3. Head Light Switch (if equipped)
4. Turn Signal Switch (if equipped)
5. Horn Button (if equipped)
6. Center Compartment
7. Power Outlet, 12V (if equipped)
8. USB Port (if equipped)
9. Accelerator Pedal
10. Brake Pedal
11. Parking Brake
12. Hour Meter (if equipped)
13. Direction Selector
14. Choke
3
5
11
10
9
2
1
4
13
14
12
Front of Vehicle
7
6
8
Front of Vehicle
