B
INTRODUCTION
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
23
Owner’s Manual
12-Volt Power Outlet (if equipped)
A 12-Volt power outlet (7) is located to the left of the center com-
partment. The outlet supplies continuous power for any accessories
that have a 12-Volt plug (Figure 2).
USB Port (if equipped)
A USB port (9) is located to the right of the center compartment (Figure 2).
Direction Selector
To reduce the possibility of component damage, the vehicle must be completely stopped before moving the
direction selector.
The direction selector is located on the seat panel and allows the operator to select
F (forward) or R (reverse). The vehicle should be left in F when unattended.
When you leave the vehicle, put the direction selector in the F position, engage the
parking brake, turn the key to OFF position and remove the key.
When the direction selector is moved to the R position, a reverse warning buzzer
activates.
Choke
The choke (15) is located on the seat panel below the driver seat. The
choke helps start the vehicle when the engine is cold.
