B
MAINTENANCE
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
41
Owner’s Manual
With the valve stem to the outside of the wheel,
install the wheel on the hub with lug nuts.
Tighten the lug nuts (1) with your fingers in the
cross-sequence pattern shown.
Tighten the lug nuts to 63 - 77 ft. lbs. (85 - 105
Nm) torque in 20 ft. lbs. (27 Nm) increments.
Continue to follow the cross-sequence pattern
until the correct torque is reached.
LIGHT BULB REPLACEMENT
To decrease the risk of premature bulb failure, do not allow your fingers to contact new bulbs. Use clean, dry
paper or paper towels to touch the glass part of the bulb.
Headlight (if equipped)
Make sure that the vehicle key switch is in the OFF position and the
key has been removed.
Disconnect the accessory harness (5) from the light bulb.
Turn the headlight bulb (3) clockwise and pull to remove.
Align the new bulb with the opening in the back of the headlight
assembly.
Turn the bulb (3) counter clockwise until it stops.
Connect the accessory harness (5) to the light bulb (3).
Turn Signal (if equipped)
Make sure that the vehicle key switch is in the OFF position and the key has been removed.
Remove the phillips head screw (7) and turn the retaining collar (8) to align with the turn signal bulb housing (9).
Grip the turn signal bulb housing (9) and pull backward to remove housing from the headlight assembly.
Remove the bulb from the housing and replace with a new one.
Push turn signal housing (9) into headlight assembly firmly, making sure that it is seated completely.
Turn the retaining collar (8) to secure the bulb housing and install the phillips head screw (7) to secure in place.
Taillight (if equipped)
Make sure that the vehicle key switch is in the OFF position and the key has
been removed.
Remove the two phillips head screws (10) that secure the lens (11) to the
taillight assembly.
Remove the light bulb.
Install the new light bulb.
Install the lens (11) and secure in place with the two phillips head screws
(10).
Replacement bulbs are available from a local Distributor, an authorized Branch
or the Service Parts Department.
Valve Stem Cap
Cross Sequence
Tire style may vary
1
3
5
4
7
8
9
6
11
10
