PROGRAM EXECUTION4
While executing function G81 (batch programming), the lower display shows the
letters "Con" followed by the number of parts programmed for that batch and the right
hand side of the display shows the number of parts already executed.
Display of the currently active G functions (G 1.5.91.)
The G functions that may be displayed are:
G01, G02, G03 Function G00 is not displayed
G05 G07 is not displayed
G70 G71 is not displayed
G91 G90 is not displayed
Functions: G04, G25, G26, G27, G28, G29, G45, G74, G75, G92 are not displayed
Display of the axis lag (following error) (E 0.012, e 0.025)
This display mode is mainly used when setting the machine up to help adjust the axes
of the machine.
They display the amount of following error (lag); that is, the difference between the
theoretical position of the axes (where they should be) and their real position (where
they actually are).
Display of the feedrate of the axes (F 01000)
It displays the axis feedrate being applied at the time. That is, the programmed feedrate
F multiplied by the % override.
