PageChapter: 5 Section:
PROGRAM EXECUTION 5
Display of the execution status of a call (N 010.025.12)
The CNC uses this display mode when executing a jump function: G25, G26, G27,
G28 or G29.
When not executing this type of function, it displays the following information:
N ---.---.--
When executing a jump function, the CNC executes the indicated program section a
number of times. The information appearing at the lower display looks like this:
N 050 . 120 . 16
The first 3-digit figure (050, in this example) indicates the number of the first block
being executed repeatedly.
The second 3-digit number (120, in this example) indicates the number of the last
block being executed repeatedly.
The third figure (2 digits. 16, in this example) indicates the number of repetitions left
for the program section being executed repeatedly.
Display of the selected spindle speed "S" and table (S 0250 T01)
It displays the spindle speed "S" currently selected as well as the "T" table address
currently selected.
Depending on the setting of machine parameter "P60(5)", the internal CNC table may
be used as tool table, "P60(5)=0", or as zero offset table, "P60(5)=1".
DISPLAY MODES
