Digital Brushless AC Servo Drive system - Ref. 1809 BCSD-21/116
1.2. BCSD Servodrive
1.2.1. BCSD drive General information
• Servodrive Model Designation.
BCSD 10 A M A - 01
(1)
FAGOR servo drive
(2)(3)(4)(5)(6)
(1) Model (3) Voltage
Code Model Code Voltage
BCSD BCSD A 220 V AC (Only valid for BCSD-08/10AMA)
D 400 V AC (Only valid for BCSD-10/15/20/30/50DMA)
(2) Rated Output (4) Control Mode
Code Rated Output Code Control Mode
08 750 W M Speed control
10 1.0 kW
15 1.5 kW (5) Encoder
20 2.0 kW
Code Encoder
30 3.0 kW A A 17-bit serial encoder
50 5.0 kW
(6) Version
Code Version
01 Software version
