BCSD-26/116 Digital Brushless AC Servo Drive system - Ref. 1809
1.2.2. BCSD drive Specifications and Models
Servodrive Model: BCSD - 08A 10A 10D 15D 20D 30D 50D
Applicable Servomotor Model:
FBS - 08A10A-----
FBM - - - 10D 15D 20D 30D 50D
Continuous Output Current [Arms] 4.0 6.0 3.2 5.0 6.4 9.0 15.0
Max. Output Current [Arms] 12.0 18.0 9.6 15.0 19.2 27.0 45.0
Input Power Supply
Main Circuit
Three-phase
200~230 V AC
+10% ~ -15%
(50/60 Hz)
Three-phase 380 ~ 480 V AC
+10% ~ -15% (50/60 Hz)
Control Circuit
Single-phase
200~230 V AC
+10% ~ -15%
(50/60 Hz)
24 V DC +10% ~ -15%
Main Supply
Capacity [kVA]
1.3 1.8 1.8 2.8 3.5 5.0 8.2
24VDC Supply
Capacity [W]
- - 30 30 30 45 45
Control Method SVPWM Control.
Feedback Serial Absolute Encoder: 131072P/R.
Operating Conditions
Ambient/Storage
Temperature
Ambient temperature: -20 ~ +55 ºC.
Storage temperature: -25 ~ +55 ºC.
Ambient/Storage
Humidity
5%-95% RH (with no condensation).
Elevation 1000 m or less.
Vibration/Shock
Resistance
Vibration Resistance: 4.9 m/s
2
Impact Resistance: 19.6 m/s
2
Configuration Base-mounted.
Performance
Speed Control Range 1:5000
Speed
Regulation
Load
Regulation
0~100% load: ±0.01% or less (at rated speed).
Voltage
Regulation
Rated voltage ±10%: 0% (at rated speed).
Temperature
Regulation
25 ± 25 ºC: ±0.1% or less (at rated speed).
Speed Control
Analog
mode
Reference
Voltage
±10 V DC at rated speed
(Variable setting range: ±0~10 V DC)
Max. input voltage: ±12 V
Input
Impedance
About 10 M or above.
Circuit Time
Constant
10 µs
CAN mode CAN Fagor protocol, CAN communication with CNC.
