3. Installation instructions
>
19
Ensure that the drain is adequately sized:
• Pumping volume of the steam generator in a limited period of time: 0.7 l/s.
• Average waste water temperature: 65ºC
Fig.13: Table-top models 061-101-102
If the drainage kit is installed above the oven outlet, this causes the water to overflow
into the water trap of the oven. D> 70 mm
Fig. 14: Models 201 and 202
