Falcon Dominator Series User Manual

24
7.6.4 Undo two phial clamp fixing screws as shown above.
7.6.5 Remove the four standoffs to release the two clamping plates that hold the phial
bracket in position.
Ensure when re-fitting phial clamp fixing screws that these
are not over tightened and stand proud of bracket as
shown above. Ceramic tape must be reinstalled with this
operation.
7.6.6 The Phial bracket is now free to be removed and replaced with new operating
thermostat sensor.
Ensure when refitted the tip of the thermostat is tight up against
the stop.
