MIDI Commands
MIDI commands are typically at the heart of the processing of presets and IA Slots. As an example, if a user presses a Preset
button, typically you would send a Program Change message to some set of equipment. The LF+ series of controllers are much
more sophisticated, and will allow you to send any and all available standard MIDI commands. This opens the door to much
more functionality, especially when combined with automated sequencers, PC DAW systems, etc…
The list of MIDI commands available are:
MIDI
Command
Type #
Command Name
# of
Params
Description
1
NOTE OFF
2
(0x80) Parameters are [NOTE #] [VALUE]
2
NOTE ON
2
(0x90) Parameters are [NOTE #] [VALUE]
3
PRESSURE
2
(0xA0) Parameters are [DATA1] [DATA2]
4
CC#
2
(0xB0) Continuous Controller: Parameters are [CC#] [VALUE]
5
PC#
1
(0xC0) Program Change: Parameter is [PC#]
6
AFTER PRESS
2
(0xD0) Parameters are [DATA1] [DATA2]
7
PITCH
2
(0xE0) Parameters are [DATA1][DATA2]
