Before discarding packaging materials, be certain all parts have been removed
Parts List
Model #FP320**1
Ref. # Description Part #
1 Hanger Bracket Assembly APG610BL
3 Ceiling Canopy
PG165
Hardware Bag Containing:
HDWFP320**
4 5/32˝-32 x19 mm Threaded Rods (2)
5 5/32˝ External Lockwasher (2)
6 Knurled Knobs (2)
13 10–32 x ½˝ Flywheel Screws (10)
14 Wire Connectors (3)
20 Chain Coupler
21 Chain Fob
2 Downrod/Hanger Ball Assembly Containing:
ADR1-6**
7 Downrod
8 Clevis Pin
9 Bridge Pin
10 Fan Motor Assembly
AMA320
11 Switch Cup Housing Assembly
AP3245
12 Wiring Harness
AP3230
15 Cover Blade Holders (Set of 5)
AP3220
16 Blade Holders (Set of 5)
AP3210
Blade Mounting Hardware Bag Containing:
BMH5
17 3/16˝-24 x 1/2˝ Phillips Screws (11 pc)
18 Phillips Screwdriver
19 Motor Coupling Cover
APPYJ1401**
Insert FINISH CODES (Refer to fan model number located on downrod support)
How To Order Parts
When ordering repair parts, always
give the following information:
• Part Number
• Part Description
• Fan Model Number
Contact your retail store for repair parts.
