NOTE: If you are uncertain of part description, refer to exploded view illustration.
1. Check to see that you have received the following parts:
Do not install or use fan if any part is damaged or missing. This product is designed to use only those parts
supplied with this product and/or any accessories designated specifically for use with this product by Fanimation.
Substitution of parts or accessories not designated for use with this product by Fanimation could result in
personal injury or property damage.
4
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each step is completed, place a check
mark in the box. This will insure that all steps have been completed and will be helpful in finding your place should
you be interrupted.
Ceiling Canopy (1)
Hanger Bracket
Assembly
(1)
Hardware Bags
Steel Cap (1)
Blade Holder Set (1)
Blade Set
(1)
Blade Cover Set
(1)
Light Plate Assembly (1) LED Assembly (1)
This manual is designed to make it as easy as possible for you to assemble,
install, operate and maintain your ceiling fan
Tools Needed for Assembly
(Not Included)
ne hillips head screwdriver
One stepladder
nstalled ire ength
ire i e
Before assembling your ceiling fan, refer to section
on proper method of wiring your fan (page 10). If you
feel you do not have enough wiring knowledge or
experience, have your fan installed by a licensed
electrician.
WARNING
!
One wire stripper
p to ft
ft
One lade
screwdriver
Materials
iring outlet o and o connectors ust e of type
re
uired y the local code he ini u wire would e a
conductor wire with ground of the following si e:
NOTE:
Place the parts from the loose parts bags in a small
container to keep them from being lost. If any parts are
missing contact your local retailer.
Light Kit Assembly (1)
Motor Assembly (1)
Canopy Screw
Cover Assembly (1)
Motor Coupling
Cover Assembly (1)
Wire Connectors (4)
3/16˝ -24
Serrated Head Screws (28)
1/4˝ -20 Pan Head Screws
with Lock Washer (28)
Downrod/Hanger Ball
Assembly (1)
– Downrod (1)
– Hanger Ball (1)
– Set Screw (1)
– Hairpin Clip (1)
– Clevis Pin (1)
– Pin (1)
Hand-Held Remote (1)
Wall Plate (1)
Screws (2)
Batteries (2)
Receiver (1)
Wire Connectors (9)
To Next Page
