86
MAINTENANCE
Position light bulb
Do not tug on the electric cables to take out the lamp-holder.
– Grasp the lamp-holder and pull it out of its seat.
– Take out the position light bulb (1) and replace it with one
of the same type.
Dipped/full beam bulb
– Do not tug on the electric cables to remove the bulb electric connector.
– Remove the black rubber sleeve from the central lamp-holder.
– Release the lamp-holder retaining spring (3) and remove it.
– Draw out the lamp-holder (2) from the parabola seat.
– Press the bulb gently and turn it counter clockwise.
– Take out the bulb from its seat.
Once the bulb has been changed, just proceed with the disassembly stages in the reverse order in order to remount the
optical unit.
1
3
2
